When it comes to the FX8 i have two dreams. But before I start dreaming, let`s assume some points this unit should can handle:
Multi-FX for real Amp Players / 4CM: No serious Player like to feed Power Chord & 4 Audio-cables to and from his Amp. The T.C. G-System handles this issue with the possibility to break out the processor unit from the MIDI foot controller. Result: Only one cable to the foot unit and shorter audio cables (higher audio quality) to and from the Amp. I think, this should can do the FX8 also! ONE cable to your feet!
Secondly we know the FW8 can act as MIDI foot controller and handle also Scenes, like Matt stated. I hope, not just "inhouse", but also for external devices – the Axe-Fx II.
So what could be the benefit of the FX8 for us – the Axe-Fx II & MFC-101 Players? The hope for an EXPANSION for the MFC (yeah, this is the reason the CAT port on MKI units named EXPANSION!) died – I believe - with FW 2 for the MFC as result to fasten up switching response (IMHO).
Now – the FX8 could be the Extension some of us (YEK?!
) are waiting for so long. 8 more switches to handle scenes beside 17 IAs for only FX control – that`s the goal. But how to connect? Beside the Cable from the MFC to the Axe-Fx another MIDI cable fromt the FX8 to the Axe-Fx Midi in? Whats with powering up the FX8? Third cable on the floor for powering up just the FX8? Meh …
And who is willing to spent the money for the FX8, only to get 8 additional SCENES or IA Switches? Power User running out of CPU on their Axe-Fx`es, so we like to have the additional FX Power of the FX8 also in our setup, right?
Yes, I know, the FX8 is developed not for Axe-Fx Players in the first line, but wouldn`t it make sense when thinking cross-selling? Or up-selling for FX8 Owners to an Axe-Fx?
So let`s start dreaming: The FX8 should be in fact a TWO-UNIT solution! Similiar like the G-system do: A break out box doin` all the analog (& digital) connections.With additional Rack-ears it should be fit in 1HE 19" Rack!
Dream 1 – My "realistic" dream:
(open image with right click in new window for fullsize!)
FX8 for 4CM / real AMP players:
- Programming, processing and controlling is done in the floor unit.
- The RJ45 EXPANSION feed power, MIDI and 8 Audio channels digital (stereo in/out ONE and stereo in/out TWO = 8 channels).
- The FX8 Break Out Box handles the analog I/Os, Power, S/PDIF (=in/out ONE, like on the Axe-Fx)
- (MIDI in/out/thru perhaps also in the break out Box…)
FX8 for Axe-Fx II XL & MFC-101 MKIII players:
- On the FX8 and the FX8 Break out Box the FASLINK and EXPANSION/RJ45 connections echo their MIDI input/output to eachother. This means: ONE Cable from the Rack to the floor. MFC-101 and FX8 are connected via short XLR cable (FASLINK).
- MFC handle 17IAs; FX8 8 SCENES. Communication is bi-directional.
- Both Units will be powered thru the Axe-Fx OR the FX8 break out box.
- Via S/PDIF connection the Axe-Fx Out1 Signal feeds into the FX8 or vice versa. So, the FX8 can be used as PRE or POST Axe-Fx II-Amp Sim FX Processor without extra AD/DA conversions.
Dream 2 – My "dreaming the dream" dream:
(open image with right click in new window for fullsize!)
Let`s entlarge the technique also for Axe-Fx MKI & MKII and MFC-101 MKI & MKII player:
- Instead of FASLINK Adapters, the FX8 & FX8 break out box supports a second EXPANSION/RJ45 port. This port is a up/down LINK from the EXPANSION port, linking all the MIDI communication (and power).
Let`s go on further and think the "impossible":
- The Axe-Fx II (and also the FX8 boxes) can also handle all 8 digital audio channels via EXPANSION. (Refering to Audinate )
- A new "FX8 LOOP"-Block (digital FX Loop OUT2/IN2) in the Axe-Fx echo the signal path to and from digital IN/OUT2 of the FX8.
So, two digital routings where thinkable:
(open image with right click in new window for fullsize!)
Dreaming the future:
Let`s think UAD extension cards: The more you plug into your computer, the more processing power can handle more plugins on the same surface (DAW). The surface could be probobly a Axe-Fx III, the plugin`s in DAW world are the Blocks in Fractal world and the UAD extension cards are ... hmmm, this:
- Let`s put the CPU processing out of the FX8, into (my dreamed) FX8 Break Out Box! Erase all the connections, but for the EXPANSION and LINK ports (and maybe Power). Ready is the FAS CPU Expansion for the upcoming Axe-Fx generation
- Instead of a FX8 Editor and Axe-Edit we`ll see a FAS Editor: When opened, the Editor checks, which units are connected (Axe-Fx III standalone, FX8 standalone, Axe-Fx III + FX8, Axe-Fx III + FAS CPU Expansion box, etc.... the "FAS Editor" will scale the Matrix to the correct size: 4x12 (Axe-Fx), 4x8 (FX8, 4x16 (FX8 + FAS CPU Expansion box), 4x20 (Axe-Fx + FAS CPU Expansion box), etc... Different background colors will show you where one unit ends and the next starts ...
So, in conclusion: Let`s think FAS world modular and scalable... this is my dream ... ( hello Supertramp ... )
